Building a High-Speed, Self-Hosted CI/CD Pipeline using GitLab Runner on Bare Metal

To ensure every CI/CD job runs in a clean, reproducible environment, we will use the Docker Executor. This means the GitLab Runner will spin up a fresh Docker container for every single job, run the commands, and then destroy the container.

Connect to your fresh Ubuntu 24.04 LTS dedicated server via SSH and install Docker:

sudo apt update && sudo apt upgrade -y
sudo apt install docker.io -y
sudo systemctl enable --now docker


To ensure the GitLab Runner can interact with the Docker daemon without running into permission errors, verify that Docker is running smoothly:

sudo docker info


GitLab provides pre-compiled binaries for Linux. We will download the official AMD64 binary, make it executable, and install it as a system service.

Download the binary:

sudo curl -L --output /usr/local/bin/gitlab-runner https://gitlab-runner-downloads.s3.amazonaws.com/latest/binaries/gitlab-runner-linux-amd64


Give it execution permissions:

sudo chmod +x /usr/local/bin/gitlab-runner


Create a dedicated system user for the runner (for security best practices) and install the service:

sudo useradd --comment 'GitLab Runner' --create-home gitlab-runner --shell /bin/bash
sudo gitlab-runner install --user=gitlab-runner --working-directory=/home/gitlab-runner
sudo gitlab-runner start


Now we need to link this bare-metal server to your GitLab repository.

1. Log into your GitLab account.

2. Navigate to your Project (or Group) > Settings > CI/CD.

3. Expand the Runners section.

4. Click New project runner.

5. Add a tag like bare-metal-speed and click Create runner.

6. GitLab will generate a Runner Authentication Token. Copy it.

Back on your server's terminal, run the registration command:

sudo gitlab-runner register


You will be prompted to answer a series of questions:

• GitLab instance URL: Enter https://gitlab.com/ (or your self-hosted GitLab URL).

• Registration token: Paste the token you copied from the UI.

• Description: Enter iDatam Bare Metal AMD EPYC Runner.

• Tags: Enter bare-metal-speed (this is how you tell your pipelines to use this specific server).

• Executor: Type docker.

• Default Docker image: Type ubuntu:22.04 (or alpine:latest).

By default, GitLab Runner only processes one job at a time. If you rented a massive 64-core AMD EPYC server, running one job at a time is a terrible waste of resources. We need to unlock parallel execution.

Edit the GitLab Runner configuration file:

sudo nano /etc/gitlab-runner/config.toml


At the very top of the file, locate the concurrent setting. Change it from 1 to the number of simultaneous jobs your server can handle (e.g., if you have 32 threads and lots of RAM, you can safely set this to 16 or 32):

concurrent = 16
check_interval = 0


Next, scroll down to the [runners.docker] section. We want to ensure Docker leverages the speed of your NVMe drives and doesn't run out of memory during massive builds. Add or modify the shm_size (Shared Memory) if your build scripts rely on it:

 [runners.docker]
    tls_verify = false
    image = "ubuntu:22.04"
    privileged = false
    disable_entrypoint_overwrite = false
    oom_kill_disable = false
    disable_cache = false
    volumes = ["/cache"]
    shm_size = 2147483648 # Allocates 2GB of shared memory for heavy containers


Save the file and restart the runner to apply the new parallelization limits:

sudo gitlab-runner restart


Your server is now listening for jobs. Let's force your code repository to use it.

In your GitLab project, create or edit your .gitlab-ci.yml file. You simply need to add the tags parameter to your jobs to ensure they route to your new iDatam server instead of the slow shared cloud runners.

stages:
  - build
  - test

compile_massive_app:
  stage: build
  image: node:20
  tags:
    - bare-metal-speed # This forces the job to use your new dedicated server!
  script:
    - echo "Compiling on bare metal..."
    - npm install
    - npm run build

run_heavy_tests:
  stage: test
  image: python:3.11
  tags:
    - bare-metal-speed
  script:
    - echo "Running heavy integration tests..."
    - pip install -r requirements.txt
    - pytest


Commit the file, and watch your CI/CD pipeline execute instantly without waiting in a queue.

You have successfully freed your software team from the constraints of cloud SaaS limits. By hosting your own GitLab Runner, you can execute thousands of parallel tests, build massive Docker images, and deploy code dozens of times a day—all for a fixed, predictable cost.

When developer time is your most expensive asset, every second spent waiting for a code compilation is money burned.

To give your engineering team the ultimate advantage, deploy your CI/CD pipelines on iDatam’s Dedicated Servers. Pair our massive multi-core AMD EPYC processors with PCIe Gen 5 NVMe arrays, and reduce your build times from 30 minutes to 3 minutes. Stop counting CI/CD minutes, and start shipping code.
