Hosting Unreal Engine 5 Dedicated Servers with Kubernetes and Agones on Bare Metal

To run Agones, we first need a Kubernetes cluster. For a bare-metal dedicated server, installing full upstream Kubernetes can be overly complex and resource-heavy. Instead, we will use K3s, a highly optimized, lightweight, and production-ready Kubernetes distribution.

Log into your fresh Ubuntu 24.04 LTS dedicated server via SSH and run the K3s installation script:

curl -sfL https://get.k3s.io | sh -


Configure your kubectl environment so you can interact with the cluster:

mkdir -p ~/.kube
sudo cp /etc/rancher/k3s/k3s.yaml ~/.kube/config
sudo chown $(id -u):$(id -g) ~/.kube/config
export KUBECONFIG=~/.kube/config


Verify that your single-node cluster is online and Ready:

kubectl get nodes


Agones is installed via Helm, the package manager for Kubernetes. First, install Helm:

curl https://raw.githubusercontent.com/helm/helm/main/scripts/get-helm-3 | bash


Next, add the official Agones Helm repository and update your local chart cache:

helm repo add agones https://agones.dev/chart/stable
helm repo update


Now, install Agones into a dedicated Kubernetes namespace. We will set the gameservers.namespaces parameter so Agones knows where to look for your UE5 instances:

kubectl create namespace agones-system
helm install my-release --namespace agones-system --set agones.ping.http.expose=false --set agones.ping.udp.expose=false agones/agones


Verify the Agones controller is running:

kubectl get pods --namespace agones-system


(You should see agones-controller, agones-allocator, and agones-extensions all in a Running state).

Before Agones can scale your game, your Unreal Engine 5 dedicated server must be packaged as a Linux Docker container.

While a full UE5 cross-compilation tutorial requires its own article, the high-level workflow is:

1. Package your UE5 project for Linux (Server build).

2. Write a Dockerfile that uses a lightweight base image (like ubuntu:22.04).

3. Integrate the Agones SDK into your UE5 C++ code so the game server can tell Kubernetes when it is "Ready" for players, and when it is "Shutting Down."

4. Build and push the image to a container registry (e.g., Docker Hub, GitHub Container Registry).

A simplified Dockerfile looks like this:

FROM ubuntu:22.04
RUN useradd -m ue5
USER ue5
WORKDIR /home/ue5

# Copy your packaged UE5 Linux Server files
COPY --chown=ue5:ue5 ./LinuxServer/ ./
RUN chmod +x ./MyGameServer.sh

# Expose the default UE5 UDP port
EXPOSE 7777/udp
ENTRYPOINT ["./MyGameServer.sh", "-log"]


A Fleet is an Agones concept that manages a pool of warm, ready-to-play game servers. Instead of starting a server from scratch when a player clicks "Matchmake" (which takes seconds), a Fleet ensures X number of servers are always running and waiting in the background.

Create a file named ue5-fleet.yaml:

nano ue5-fleet.yaml


Paste the following configuration (replace your-registry/ue5-server:latest with your actual Docker image):

apiVersion: "agones.dev/v1"
kind: Fleet
metadata:
  name: ue5-fleet
spec:
  replicas: 5 # Always keep 5 servers warm and ready
  template:
    spec:
      ports:
      - name: default
        portPolicy: Dynamic # Agones will dynamically assign a host port
        containerPort: 7777 # The internal port your UE5 server binds to
      template:
        spec:
          containers:
          - name: ue5-server
            image: your-registry/ue5-server:latest
            resources:
              requests:
                memory: "2Gi"
                cpu: "1000m"
              limits:
                memory: "4Gi"
                cpu: "2000m"


Apply the Fleet configuration to your Kubernetes cluster:

kubectl apply -f ue5-fleet.yaml


Within moments, Agones will spin up 5 identical instances of your UE5 dedicated server.

Check the status of your GameServers:

kubectl get gs


The output will list the 5 servers, their STATE (which should transition from Starting to Ready), and the exact ADDRESS and PORT that players can connect to.

When your custom matchmaking service needs a server for a new lobby, it simply asks the Agones Allocator API for a server. Agones changes that server's state to Allocated, gives the IP and Port to the players, and automatically spins up a new Ready server to replace it in the Fleet.

By combining the orchestration power of Kubernetes and Agones with raw bare-metal hardware, you have built a world-class backend capable of supporting millions of players dynamically—without the crushing per-minute compute costs of the public cloud.

However, in multiplayer gaming, compute is only half the battle. If a single disgruntled player targets your host node with a UDP flood, your entire Kubernetes cluster could go offline.

When you deploy your Agones fleet on iDatam’s DDoS Dedicated Servers, you secure your infrastructure at the hardware layer. Our edge-scrubbing centers instantly filter out volumetric Layer 3/4 attacks before they ever reach your nodes, ensuring your Unreal Engine 5 matches remain perfectly synchronized, and your players stay in the game.
